| ITEM | SPECIFICATION |
|---|---|
| carburetor type | Mikuni BST32SS |
| Bore size | 32 mm |
| I.D. No | 10D2 |
| Idle rpm | 1,400 ± 50 rpm |
| Float height | 14.6 ± 1.0mm |
| Main Jet (M.J) | #102.5 |
| Main air jet (M.A.J.) | 0.6 mm |
| Jet needle (J.N.) | 5EZ74 |
| Needle Jet (N.J.) | O-9 |
| Throttle Valve (Th.V.) | #130 |
| Pilot jet (P.J.) | 32.5 |
| By-pass (B.P.) | #1 0.8, #2 0.8, #3 0.8 mm |
| Pilot outlet (P.O.) | 0.8 mm |
| Valve seat (V.S.) | 2.0 mm |
| Starter Jet (G.S.) | #32.5 |
| Pilot screw | PRE-SET |
| Throttle cable play | 0.5-1.0 mm (0.02-0.04 in) |
